Product Details:
|
|
| Place of Origin: | Chongqing, China |
|---|---|
| Brand Name: | DFSK |
| Certification: | EEC/COC |
| Model Number: | DFSK ec35/ec36 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 unit |
| Price: | Negotiable |
| Packaging Details: | By Container |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 70000 units per year |
|
Detail Information |
|||
| Product Name: | DFSK Ec35/ec36 | Length × Width × Height (mm): | 4500*1680*1985 |
|---|---|---|---|
| Curb Weight (kg): | 1510 | Certification: | EEC/COC |
| Gross Weight Kg: | 2600 | Max Speed (km/h): | 80/100 |
| Seater: | 2/4 | Battery Capacity (kWh): | 38.7 |
| Wheelbase (mm): | 3050 | Tire: | 185R14LT 8PR |
| Highlight: | dfsk electric minivan,electric minivan ec35,ec36 mini van lhd |
||
Product Description
Specification
| Item |
L1(LHD)
|
R1(RHD)
|
||
|
Basic
|
Optional
|
Basic
|
Optional
|
|
|
Gotion (Lithium Iron Phosphate)
|
Gotion (Lithium Iron Phosphate)
|
|||
|
Basic Parameter
|
||||
| Length × Width × Height (mm) | Box van:4500*1680*1985 | Box van:4500*1680*1985 | ||
|
Wheelbase (mm)
|
3050 | 3050 | ||
|
Wheel tread (mm)
|
1435/1435 | 1435/1435 | ||
|
Curb weight (kg)
|
1510 | 1510 | ||
|
Gross weight kg
|
2600 | 2600 | ||
| Acceleration time of 0-50km/h | ＜10S | ＜10S | ||
| Acceleration time of 50-80kW/h | ＜15S | ＜15S | ||
|
Max Speed (km/h)
|
80 | 100 | 80 | 100 |
|
Seating capacity
|
2 | 2+2 | 2 | 2+2 |
|
Electric drive and rear axle
|
||||
| Motor Type | Greatland: TZ210XSR41/Permanent Magnet Synchronous Motor |
Greatland: TZ210XSR41Permanent Magnet Synchronous Motor |
||
|
Motor Cooling Method
|
Water cooling | Water cooling | ||
| Rated Power/Peak Power (KW/rpm) | 30/3600—60/9000 | 30/3600—60/9000 | ||
| Rated torque / Peak torque(N.m) | 80/200 | 80/200 | ||
|
Drive axle speed ratio
|
10.5 | 10.5 | ||
|
Estimated Range [WLTP]
|
Max. speed 80:268km | Max. speed 100:163km | Max. speed 80:268km | Max. speed 100:163km |
|
Voltage
|
307.2 | 307.2 | ||
|
Battery capacity kWh
|
38.7 standard:With heating and maintenance switch | 38.7 standard:With heating and maintenance switch | ||
|
OBC power
|
6.6KW | 6.6KW | ||
|
Transmission/Reducer
|
NA | NA | ||
|
System structure
|
||||
|
Body Type
|
Integral body | Integral body | ||
|
Drive Mode
|
Rear egine, rear drive | Rear egine, rear drive | ||
|
Front Suspension
|
MacPherson Independent Suspension | MacPherson Independent Suspension | ||
|
Rear Suspension
|
Non-independent 5-leaf-spring suspension | Non-independent 5-leaf-spring suspension | ||
|
Brake
|
Front disc and rear drum, Mechanical Parking Brake | Front disc and rear drum, Mechanical Parking Brake | ||
|
Steering Type
|
EPS | EPS | ||
|
External Configuration
|
||||
|
Tire
|
185R14LT 8PR | 185R14LT 8PR | ||
|
Tire Rim
|
Silver steel wheel( optional black steel spare tire ) | Silver steel wheel( optional black steel spare tire ) | ||
| Wheel Cover | Steel wheel decoration cover (DFSK logo) | Steel wheel decoration cover (SOKON logo) | Steel wheel decoration cover (DFSK logo) | Steel wheel decoration cover (SOKON logo) |
|
Wheel Nut
|
Galvanized nuts | Galvanized nuts | ||
|
Front/Rear Bumper
|
the same color | the same color | ||
|
Grille
|
same color | same color | ||
|
Front/rear mudguard
|
IA,without logo | IA,without logo | ||
| Front combination headlight | European standard regulation requirements: automatic headlight lighting function | European standard regulation requirements: automatic headlight lighting function | ||
|
Front fog light
|
IA | IA | ||
|
Daytime running light
|
European standard regulation requirements:IA | European standard regulation requirements:IA | ||
|
Side turn signal
|
White lamp shade and yellow light bulb | White lamp shade and yellow light bulb | ||
|
Wiper
|
Front wiper( with bone ) | Front wiper( with bone ) | ||
| Exterior Rear view Mirror | Standard type, matt black, external manual adjustment | Electric Exterior Rearview Mirror | Standard type, matt black, external manual adjustment | Electric Exterior Rearview Mirror |
|
Sunroof
|
NA | NA | ||
|
Outer handle
|
Matt black | Matt black | ||
| Glass | 2 seats:lift glass for front door,panel for middle sliding door/rear side ；glass for back door | 2 seats:lift glass for front door,panel for middle sliding door/rear side ；glass for back door | ||
| 4 seats:lift glass for front door,glass for middle door;glass for back door,panel for rear side | 4 seats:lift glass for front door,glass for middle door;glass for back door,panel for rear side | |||
"●" - indicates that this configuration is available, "○" - indicates that this configuration is optional,
and "-" - indicates that there is no such configuration;
