Product Details:
|
|
| Place of Origin: | Chongqing, China |
|---|---|
| Brand Name: | DFSK |
| Certification: | EEC/COC |
| Model Number: | DFSK K01H |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 unit |
| Price: | Negotiable |
| Packaging Details: | By Container |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 70000 units per year |
|
Detail Information |
|||
| Product Name: | DFSK K01H | Displacement(L): | 1.24 |
|---|---|---|---|
| Fuel: | Gasoline | Emission Standard: | EuropeⅥ |
| Transmission Type: | 5 MT | Steering Type: | EPS |
| Clutch Type: | Mechanic | Fuel Tank: | Metal Fuel Tank,40L |
| Body Type: | Semi-loaded Body | ||
| Highlight: | eps eu certificate vehicles,eps left hand drive truck,dfsk eu certificate vehicles |
||
Product Description
Specification
|
Item
|
L3
|
L4
|
||||
|
Engine and rear axle
|
||||||
|
Engine
|
AF10-06 | BG13-20 | AF10-13 | DK12-06 | DK12-06 | DK12-06 |
|
Speed Ratio
|
43:9 | 43:11 | 41:8 | 41:8 | 41:8 | 41:8 |
|
Emission Standard
|
China Ⅳ |
China Ⅳ | China Ⅳ | EuropeⅥ | EuropeⅥ | EuropeⅥ |
|
Displacement
|
0.997L | 1.3L | 1.05 | 1.24 | 1.24 | 1.24 |
| EFI | UMC M7.8.0 |
UMC M7.8.0 |
Delphi MT22.1/LINGDIAN LEC4AF | Delphi MT22.1 | Delphi MT22.1 | Delphi MT22.1(OBD oil mass function) |
|
Transmission Type
|
5 MT | 5 MT | 5 MT | |||
|
System structure
|
||||||
|
body type
|
Semi-loaded body | Semi-loaded body | ||||
|
Drive Mode
|
Mid-engine,rear-drive | Mid-engine,rear-drive | ||||
|
Front Suspension
|
McPherson independent suspension | McPherson independent suspension | ||||
| Rear Suspension | Non-Independent Suspension With 5-Bar Leaf Spring Type | Non-Independent Suspension With 5-Bar Leaf Spring Type | ||||
| brake | Front-disc rear drum, dual circuit hydraulic brake | Front-disc rear drum, dual circuit hydraulic brake | ||||
| Steering Type | basic:Mechanic optional:EPS |
EPS | EPS | |||
|
clutch type
|
Mechanic | Mechanic | ||||
|
External configuration
|
||||||
|
tire
|
165/R13LT | 165/70R14 | 165R13LT | |||
|
Wheel
|
silver steel wheel,steel spare tire (silver) | steel wheel,steel spare tire (silver) | ||||
|
Wheel Rim Cover
|
steel decorative cover | steel decorative cover | ||||
|
wheel nut
|
galvanized nut | galvanized nut | ||||
|
front/rear bumper
|
the same color bumper | the same color bumper | ||||
|
grille
|
the same color | the same color | ||||
|
Front/Rear Mudguard
|
IA,without mark | IA,with mark | ||||
| Headlight | basic:double headlights, manual adjustment optional:double headlights, electric adjustment |
double headlights, manual adjustment | double headlights, electric adjustment | |||
|
Front Fog Light
|
double front fog lights | double front fog lights | ||||
| Daytime running light assembly | basic:NA optional:LED |
NA | IA | |||
| Turn signal | Yellow light bulb with white shade | on the fender,yellow light bulb with white shade | on the fender,yellow light bulb with white shade | |||
| Wiper | multi-stage front wiper | front wiper,without rear wiper | front wiper with bone,without rear wiper | |||
| Exterior Rear-View Mirror | Enlarged exterior rear-view mirror, mirror housing in body color, mirror base in black | Enlarged exterior rear-view mirror,body color | ||||
| Outside Handle | basic: IA,matte black optional:IA,chrome plated outside handle |
IA,matte black | IA,matte black | |||
| Glass | front door:lift glass;side window and back panel: glass | front door:lift glass;side window and back panel: glass | ||||
| Window Glass Lifter | basic;manual optional:electric |
electric front door | basic;manual optional:electric |
|||
| Outer cut water glue strip | black | black | ||||
| Reversing light(rear combination lamp) | double reversing lights | double reversing lights(rear combination strip light) | ||||
| Rear fog light | double rear fog lights(rear combination strip light) | double rear fog lights(rear combination strip light) | ||||
| Retro Reflector | NA | Non-independent,rear combination strip light | Non-independent,rear combination strip light | |||
| High-Mount Brake Light | NA | NA | ||||
| Mark | model number:K01H rear sign:Mini Truck |
model number:K01H front logo:DONGFENG nameplate:hard rear sign:Mini Truck SRS+ABS mark |
model number:K01H front logo:DONGFENG nameplate:hard rear sign:Mini Truck SRS+ABS mark |
|||
|
Decal
|
DONGFENG logo+DFSK | DONGFENG logo+DFSK | ||||
| Muffler Heat Sheild | NA | NA | ||||
| Muffler Cover | NA | NA | ||||
| Engine cover | NA | NA | ||||
| Engine Decoration | NA | NA | ||||
|
Fuel Tank
|
metal fuel tank,40L | metal fuel tank,40L | ||||
| Fuel Tank Opening Mode | Key | Key | ||||
|
Internal Configuration
|
||||||
|
Interior Trim Style
|
Nissan black | Nissan black | ||||
| Sun Visor | Gray, double-visor (standard type), driver seat with ticket belt, front passenger seat with make-up mirror | Gray, double-visor (standard type), driver seat and front passenger seat with ticket belt and without make-up mirror | ||||
| Inside Rear-View Mirror | Luxury type,gray | Luxury type,gray | ||||
| Dashboard | basic: Nissan black body; side air vents (titanium silver + Nissan black), titanium silver center control panel opyional: double airbags dashboard |
K-series double airbags dashboard; Nissan black body and speaker cover; matte center air vent silver, chrome side vent; Nissan black large panel of dashboard; Nissan black toolbox lock handle and hood handle | K-series double airbags dashboard; Nissan black body and speaker cover; matte center air vent silver, chrome side vent; Nissan black large panel of dashboard; Nissan black toolbox lock handle and hood handle | |||
| Combination instrument | basicz; digital (with tachometer) optional: digital (with tachometer) |
digital(new shape) | digital(new shape) | |||
| Multi-Media System | basicz; MP3 optional: CD |
MP3 | MP3 | |||
|
Speaker
|
2 | 2 | ||||
| Warm air manipulation mechanism | Knob type | Knob type | ||||
|
Cigarette Lighter
|
IA | IA | ||||
|
Ash box
|
IA | IA | ||||
| Steering Wheel | basic: comfortable type, Nissan black optional:double airbags |
K-series airbag steering wheel, Nissan black | K-series airbag steering wheel, Nissan black | |||
| Upper & Down Cover of Combination Switch | basic:Nissan black optional:Upper & Down Cover of airbag |
Nissan black, with clock spring | K-series combination switch with clock springs; Nissan black upper & down cover of airbag | |||
|
Gear-Shift
|
Nissan black | Nissan black | ||||
|
Hand Brake
|
Nissan black | Nissan black | ||||
| Control box + rear cover + cup holder | Nissan black, with cupholder | Nissan black, with cupholder | ||||
| Front reading light | front reading light only: 3 light bulbs | front reading light only: 3 light bulbs | ||||
| Front door light switch | IA | basic:NA optional:IA |
||||
|
Rear door light switch
|
NA | NA | ||||
|
Horn
|
Basin type | Basin type | ||||
| A/C | basic:NA optional:single steam |
single steam | single steam | |||
| Interior trim panels (door/side) | basic: standard heat-sealing lines, Nissan black artificial leather optional:K01H shaped injection-molded interior panel, without triangular trim pieces, Nissan black body, silver trim pieces and cover ; Nissan black armrest cover (when electric windows and doors are available) rear side:Nissan black artificial leather |
front door:K01H shaped injection-molded interior panel, without triangular trim pieces, Nissan black body, silver trim pieces and cover ; Nissan black armrest cover rear side:Nissan black artificial leather |
basic: standard heat-sealing lines, Nissan black artificial leather optional:K01H shaped injection-molded interior panel, without triangular trim pieces, Nissan black body, silver trim pieces and cover ; Nissan black armrest cover (when electric windows and doors are available) rear side:Nissan black artificial leather |
|||
|
Pillar trim
|
NA | NA | ||||
|
top roof
|
gray, printed lining for hard top | gray, printed lining for hard top | ||||
|
Safety Handle
|
1,gray | 1,gray | ||||
| Handle (mounted on the pillar) | NA | NA | ||||
| Handrail + crank handle | basic:Nissan black optional:NA |
Nissan black, integrated with the interior panel | basic:Nissan black,common type of K series optional:Nissan black, integrated with the interior panel |
|||
| Interior Handle | basic:front door, Nissan black,common type of K series optional:front door,Nissan black (titanium silver handle), injection molded interior panel |
front door,Nissan black (titanium silver handle), injection molded interior panel | basic:Nissan black,common type of K series optional:front door,Nissan black (titanium silver handle), injection molded interior panel |
|||
| Locking button + bushing | Nissan black | Nissan black | ||||
|
Seats
|
2 seats, black fabric:M080+M081 | 2 seats, black fabric:M080+M081 | ||||
| Front-Row seats | driver seat and front passenger seat with sliding rail, headrest is fixed to the rear panel,seat belt lock on the floor | driver seat and front passenger seat with sliding rail, headrest is fixed to the rear panel,seat belt lock on the floor | ||||
|
Second-Row Seats
|
NA | NA | ||||
|
Seat Hinged Cover
|
NA | NA | ||||
| safety belt | European standard, Nissan black | Nissan black front row: 3+3, common type |
Nissan black front row: 3+3, common type |
|||
|
Floor Mat
|
M015, 2.0mm foam | 2.0mm(M015) | ||||
| Carpet noise insulation cotton | NA | NA | ||||
| front floor insulation pad | IA | IA | ||||
|
Floor Mat
|
Nissan black | Nissan black | ||||
|
Flooring strips/steps
|
NA | NA | ||||
|
Security and intelligence
|
||||||
| airbag | basic:NA optional:double airbags |
double airbags | double airbags | |||
|
Child lock
|
NA | NA | ||||
| ABS | basic:NA optional:IA |
ESC' self-contained founction | IA | |||
| Central Lock | basic:NA optional:mechanical control for front door |
NA | basic:NA optional:mechanical control for front door remote control for front door |
|||
| key | intergrated key | basic:intergrated key optional:remote control key(integrated key, one handle with remote control, one handle without remote control) |
||||
| Immobilizer | NA | NA | ||||
| Body Anti-Theft | NA | NA | ||||
| ESP/ESC | NA | IA | IA | |||
| TPMS | NA | NA | IA | |||
| EBA/BAS/BA/EVA | NA | ESC' self-contained founction | IA | |||
|
Body description
|
||||||
| Cargo box (guardrail, rail) | Basic: 2.3m cargo box, without rear fence and lift rail optional:2.5m cargo box, without rear fence and lift rail |
2.5m cargo box, without rear fence and lift rail | Basic: 2.3m cargo box, without rear fence and lift rail optional:2.5m cargo box, with rear fence and without lift rail 2.3m cargo box, with rear fence and without lift rail |
|||
| Grille / partition, sealed window | NA | NA | ||||
| Tool Box | basic:NA optional:IA |
NA | basic:NA optional:IA |
|||
| Guard bar for rear side window glass | basic:IA optional:NA |
IA | basic:IA optional:NA |
|||
|
Rear Metal Bumper
|
NA | NA | IA, double bumpers | |||
|
Others
|
||||||
| Engine Throttle | Mechanical | Basic: Mechanical Optional: Electronic |
Electronic | Electronic | ||
"●" - indicates that this configuration is available, "○" - indicates that this configuration is optional,
and "-" - indicates that there is no such configuration;
