| Item |
Basic I
L1 |
Standard I
L2 |
|
Engine and rear axle
|
|
Engine
|
DK15-06 |
DK15C |
|
Speed Ratio
|
Tubular Rear Axle(43/9) |
Tubular Rear Axle(43/9) |
|
Emission Standard
|
Europe Ⅵ |
China Ⅵ |
|
Displacement
|
1.499 |
1.498L |
|
Efi
|
Delphi MT22.1 |
Delphi MT62 |
|
Transmission Type
|
5MT |
5 MT |
|
System structure
|
|
Body Type
|
Semi-Loaded Body, Reinforced Longitudinal Beam |
Semi-Loaded Body, Reinforced Longitudinal Beam |
|
Drive Mode
|
Mid-Engine, Rear-Drive |
Mid-Engine, Rear-Drive |
|
Front Suspension
|
Mcpherson Independent Suspension |
Mcpherson Independent Suspension |
| Rear Suspension |
Non-Independent Suspension With 6-Bar Leaf Spring Type, Top-Mounted Leaf Spring |
Non-Independent Suspension With 6-Bar Leaf Spring Type, Top-Mounted Leaf Spring |
| Brake Type |
Front-Disc Rear Drum, Dual Circuit Hydraulic Brake；7+8 Double Membranes Vacuum Booster |
Front-Disc Rear Drum, Dual Circuit Hydraulic Brake；7+8 Double Membranes Vacuum Booster |
|
Steering Type
|
EPS |
EPS |
|
Clutch Type
|
Mechanic |
Mechanic |
|
External configuration
|
|
Tire Model
|
185 R14LT 8PR(European Standard) |
185 R14LT 8PR(European Standard) |
|
Wheel Rim
|
silver steel wheel, steel spare tire (silver) |
silver steel wheel, steel spare tire (black) |
| Wheel Rim Cover |
Wheel hub center cover(DONGFENG logo,optional SOKON logo) |
Steel Wheel Decorative Cover(DONGFENG logo,optional SOKON logo) |
| Wheel Nut |
basic:galvanized nut
optional:chrome plated nut(only applicable for TV03) |
galvanized nut |
|
Front/Rear Bumper
|
body color, black for middle grille |
body color, black for middle grille |
|
Grille
|
body color(C27 new shape) |
body color(C27 new shape) |
|
Front/Rear Mudguard
|
IA |
IA |
|
Front Headlamp
|
electric height adjustment |
electric height adjustment |
|
Front Fog Light
|
IA |
IA |
|
Daytime Running Light
|
IA |
IA |
|
Indicator
|
Yellow light bulb with white shade |
Yellow light bulb with white shade |
|
Wiper
|
Front wiper with bone, without rear wiper |
Front wiper with bone, without rear wiper |
| Exterior Rear-View Mirror |
Standard Exterior Rear-View Mirror, mirror housing in body color, mirror base in black |
Standard Exterior Rear-View Mirror, mirror housing in body color, mirror base in black |
|
Outside Handle
|
black |
black |
| Glass |
lift glass for front door, sliding window for middle door |
lift glass for front door, sliding window for middle door |
| Window Glass Lifter |
basic; manual front and middle door
optional: electric front door,manual middle door |
basic; manual front and middle door
optional: electric front door,manual middle door |
|
Pillar Black Film
|
NA |
NA |
| Outer Cut Water Glue Strip |
black |
black |
|
Rear Headlamp
|
Double reversing lights, rear combination light strip |
Double reversing lights, rear combination light strip |
|
Rear Fog Light
|
Double fog lights, rear combination light strip |
Double fog lights, rear combination light strip |
|
Retro Reflector
|
Non-independent, rear combination light strip |
Non-independent, rear combination light strip |
| High-Mount Brake Light |
basic: NA
optional: IA |
NA |
| Light Cover of Rear License Plate |
NA |
NA |
| Logo |
front logo:DONGFENG,optional SOKON
Nameplate:hard logo
rear mark:C32
ESC mark |
front logo:DONGFENG,optional SOKON
Nameplate:for European standard
Model number:C32 |
|
Luggage Rack
|
NA |
NA |
| Decal |
basic: Decal for back: Logo + DFSK
optional:Decal for back: Logo + DFSK
Decal for body |
Decal for back: Logo + DFSK |
|
Muffler Heat Shield
|
NA |
NA |
| Muffler Cover |
NA |
NA |
| Engine Cover |
NA |
NA |
| Engine Decoration |
NA |
NA |
| Big Surrounded |
NA |
NA |
|
Fuel Tank
|
55L |
50L |
| Fuel Tank Opening Mode |
Key |
Key |
|
Internal Configuration
|
|
Interior Trim Style
|
balck |
balck |
| Sun Visor |
Gray, double sun visors (standard type),front passenger seat with make-up mirror |
Gray, double sun visors (standard type),front passenger seat with make-up mirror |
| Interior Rear-View Mirror |
Basic: basic type, gray (from K07)
Optional: anti-dazzle interior rear-view mirror, black |
Basic: basic type, gray (from K07)
Optional: anti-dazzle interior rear-view mirror, black |
| Dashboard |
V29 Boutique dashboard
Nissan black main body |
V29 Boutique dashboard
Nissan black main body |
|
Combination Instrument
|
Digital(new shape), without door open reminder |
Digital(new shape), without door open reminder |
| Multi-Media System |
MP3
optional: MP5 |
MP3 |
|
Speaker
|
2 |
2 |
| Warm Air Manipulation Mechanism |
Knob |
Knob |
| Steering Wheel |
Basic: normal steering wheel(Dongfeng logo, optional SOKON logo)
Optional: multifunction steering wheel with airbag |
Basic: normal steering wheel(Dongfeng logo, optional SOKON logo)
Optional: multifunction steering wheel with airbag |
| Adjustable Steering Wheel |
NA |
NA |
| Combination Switch And Cover |
Nissan black |
Nissan black |
|
Gear-Shift
|
Nissan black main body |
Nissan black main body |
|
Hand Brake
|
Nissan black |
Nissan black |
| Control Box + Rear Cover + Cup Holder |
Nissan black, with cup holder |
Nissan black, with cup holder |
|
Central Armrest
|
NA |
NA |
| Interior Lights (Front/Middle/Rear) |
Integrated front reading light and interior view mirror |
Integrated front reading light and interior view mirror |
| Front Door Light Switch |
basic:NA
optional:IA |
basic:NA
optional:IA |
| Rear Door Light Switch |
basic:NA
optional:IA |
basic:NA
optional:IA |
|
Welcome Light
|
NA |
NA |
|
Horn
|
Basin type |
Basin type |
| A/C |
basic:NA
optional:single steam
optional: double-steam(only applicable for TV03) |
basic:NA
optional:single steam |
| Interior Trim Panels (Door/Side) |
Basic : front door: with fire retardant foam, standard heat bonding line, Nissan black artificial leather,
Optional : front door: injection molded interior panel, Nissan black body, brushed metal armrest cover, with front door triangle trim; middle door:front door: with fire retardant foam, standard heat bonding line, Nissan black artificial leather |
Basic : front door: with fire retardant foam, standard heat bonding line, Nissan black artificial leather,
Optional : front door: injection molded interior panel, Nissan black body, brushed metal armrest cover, with front door triangle trim; middle door:front door: with fire retardant foam, standard heat bonding line, Nissan black artificial leather |
|
Pillar Trim
|
A-pillar trim: Gray |
A-pillar trim: Gray |
|
Top Roof
|
Hard top, non-woven, gray |
Hard top, non-woven, gray |
|
Safety Handle
|
3, gray(V29) |
3, gray(V29) |
| Handle (Mounted On The Pillar) |
NA |
NA |
| Handrail + Crank Handle |
Basic: Nissan black, same as V22
Optional: Nissan black, interior panel with its own armrest |
Basic: Nissan black, same as V22
Optional: Nissan black, interior panel with its own armrest |
| Interior Handle |
Basic: Front and middle door: Nissan black, same as V22
Optional: Front door: Nissan black (chrome handle), same as V22,middle door: Nissan black, same as V22 |
Basic: Front and middle door: Nissan black, same as V22
Optional: Front door: Nissan black (chrome handle), same as V22,middle door: Nissan black, same as V22 |
| Locking Button + Bushing |
Basic: Front and middle door: Nissan black
Optional: Front door: chrome + red warning strip,middle door: Nissan black |
Basic: Front and middle door: Nissan black
Optional: Front door: chrome + red warning strip,middle door: Nissan black |
| Seats |
basic: fabric( cloth ):M085=M085+M086
optional: fabric( leather ):K033=P028+P029(only applicable for TV03) |
fabric:M085+M086 |
| Front-Row Seats |
new shape seats, 4-way adjustment for driver seat and front passenger seat , adjustable headrest , seat belt lock on the floor |
new shape seats, 4-way adjustment for driver seat and front passenger seat , adjustable headrest , seat belt lock on the floor |
|
Second-Row Seats
|
one-piece seat for 3 people, with headrest |
one-piece seat for 3 people, with headrest |
|
Seat Hinged Cover
|
NA |
NA |
| Safety Belt |
Nissan black, normal type
front row:3+3, rear row:3+2+3, |
Nissan black, normal type
front row:3+3, rear row:3+2+3, |
| Floor Mat |
Cabin carpet: gray lychee pattern, M023: 1.6mm foam
engine compartment insulation carpet:gray lychee pattern, M023: 1.6mm foam
rear floor carpet: gray lychee pattern, M023: 1.6mm foam, rear floor is not wrapped |
Cabin carpet: gray lychee pattern, M023: 1.6mm foam
engine compartment insulation carpet:gray lychee pattern, M023: 1.6mm foam
rear floor carpet: gray lychee pattern, M023: 1.6mm foam, rear floor is not wrapped |
| Carpet Noise Insulation Cotton |
NA |
NA |
| Front Panel Heat Insulation Pad |
IA |
IA |
|
Floor Mat
|
Nissan black |
Nissan black |
|
Flooring Strips/Steps
|
Nissan black |
Nissan black |
|
Ash Box
|
IA |
IA |
|
Cigarette Lighter
|
IA |
IA |
|
Security and intelligence
|
| Air Bag |
basic:NA
optional:double airbags |
basic:NA
optional:double airbags |
| Child Lock |
basic:NA
optional:child lock in back door(only applicable for TV03) |
basic:NA
optional:IA |
|
ISOFIX
|
NA |
NA |
|
Immobilizer
|
NA |
NA |
|
ABS/EBD
|
IA |
IA |
|
Reversing Radar
|
NA |
NA |
| Reversing Camera |
basic:NA
optional:IA |
NA |
| Central Lock |
basic:NA
optional:Front door with mechanical central control
optional:Front door with remote central control |
basic:NA
optional:Front door with mechanical central control
optional:Front door with remote central control |
| Key |
basic:integrated key(Dongfeng logo, optional SOKON logo)
optional: optional remote control(1 remote control key + 1 normal key, Dongfeng logo, optional SOKON logo) |
basic:integrated key(Dongfeng logo, optional SOKON logo)
optional: optional remote control(1 remote control key + 1 normal key, Dongfeng logo, optional SOKON logo) |
| ESP/ESC |
IA |
NA |
| Body Anti-Theft |
NA |
NA |
| TPMS |
IA |
IA |
| ASR/TCS/TRC/ATC |
NA |
NA |
| EBA/BAS/BA/EVA |
IA |
NA |
|
Body description
|
| Cargo Type |
Basic: 2.3m cargo box, without rear fence and lift rail
Optional: 2.3m cargo box with rear fence
Optional: 2.1m cargo box with rear fence |
Basic: 2.3m cargo box, without rear fence and lift rail
Optional: 2.3m cargo box with rear fence |
|
Guard Bar For Rear
Side Window Glass
|
IA |
IA |
|
Rear Metal Bumper
|
IA |
IA |
|
Tool Box
|
NA |
NA |
|
Others
|
| Battery Mounting Pressure Plate |
NA |
NA |
|
Visible Standard Parts
|
Color zinc |
Color zinc |
|
Muffier
|
Same as V22 (extended) |
Same as V22 (extended) |
|
Engine Throttle
|
Electronic |
Electronic |
