Product Details:
|
|
| Place of Origin: | Chongqing, China |
|---|---|
| Brand Name: | DFSK |
| Model Number: | EC31 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 unit |
| Price: | Negotiable |
| Packaging Details: | By Container |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 70000 units per year |
|
Detail Information |
|||
| Product Name: | EC31 Small Electric Box Truck | Fuel: | New Energy |
|---|---|---|---|
| Passenger: | 2 | Type: | Electric Mini Box Truck |
| Exterior Dimension: | 4750×1670×2400 Mm | Cargo Size: | 2770×1565×1550 Mm |
| Battery Capacity: | 38.64 KWh | Max. Mileage: | 275 Km |
| Power: | 60 KW | Fast Charing: | 0.6 H |
| Highlight: | Pure Electric Vans and Trucks,Electric Vans and Trucks Produce Delivery,electric cargo vans 38.64kWh |
||
Product Description
EC31 Small Electric Box Utility Truck Specification
|
Model
|
EC31 Mini Box Electric Utility Truck |
|
Basic Parameter
|
|
|
Size (mm)
|
4730*1670*1960 |
|
Wheelbase (mm)
|
3050 |
|
Wheel tread (mm)
|
1410/1410 |
|
Curb weight (kg)
|
1320 |
|
Gross weight (kg)
|
2600 |
|
Acceleration time of 0-50 km/h
|
＜10 Sec |
|
Acceleration time of 50-80 kW/h
|
＜10 Sec |
|
Max speed (km/h)
|
80 |
|
Seater
|
2 |
|
Electric Drive and Rear Axle
|
|
|
Motor Type
|
Permanent Magnet Synchronous Motor |
|
Rated Power (kW/rpm)
|
30/3600-60/9000 |
|
Rated Torque (N.m)
|
80/200 |
|
Estimated Range (WLTP)
|
275 km |
|
Battery Rated Energy
|
38.64kWh |
|
Transimmission
|
Single-spped Automatic |
|
System Structure
|
|
|
Body Type
|
Short head, Single row, Non-reversible |
|
Drive Mode
|
Rear egine, rear drive |
|
Steering Type
|
EPS |
|
Front Suspension
|
Mac pherson independent suspension |
|
Rear Suspension
|
Non-independent 6-leaf-spring top mounted |
|
Security, Intelligence
|
|
|
ABS anti-lock braking
|
● |
|
Manual air conditioning
|
● |
|
Spare wheel
|
● |
|
Vehicle tools
|
○ |
|
Charging gun
|
○ |
"●" - indicates that this configuration is available, "○" - indicates that this configuration is optional,
and "-" - indicates that there is no such configuration;
DFSK EC31 Pure Electric Box Utility Mini Truck Description
DFSK EC31 Electric Cargo Box Mini Truck
EC31 New Energy Cargo Produce Delivery Truck, 275km Mile Range Per Charging
DFSK EC31 Multifunction Electric Cargo Box Truck
Super Space and good business partner, can be used for fast food trucks, food vegetable cargo transportation
DFSK EC31 Small Electric Trucks 275km Mile Range Per Charging
Cargo size is 4730*1670*1960, 6.8 cubic meters cargo space, 1-2 tons loading weight capacity
DFSK EC31 Mini Electric Trucks 38.64kWh with Fast Charging
Approved for fast charing, 90 mins
