Product Details:
|
|
| Place of Origin: | Chongqing, China |
|---|---|
| Brand Name: | DFSK |
| Model Number: | ES50 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 unit |
| Price: | Negotiable |
| Packaging Details: | By Container |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 70000 units per year |
|
Detail Information |
|||
| Product Name: | Ruichi ES50 | Fuel: | Pure Electric |
|---|---|---|---|
| L×W×H(mm): | 4500*1680*2000 | Cargo Size(mm): | 3420×1550×1510 |
| Curb Weight(kg): | 1575 | Max Speed (km/h): | 100 |
| Power Battery Capacity (kWh): | 38.6 | Range(km): | 252 |
| Van Cargo Volume (m³): | 8 | Power Battery: | Lithium Iron Phosphate |
| Highlight: | 2024 RUICHI Electric Vans and Trucks,Electric Vans and Trucks 7 Passenger,ES50 small electric vans |
||
Product Description
Specification
| Item |
ES50
|
|
Standard version-Pioneer I
|
|
|
Basic Parameters
|
|
|
L×W×H(mm)
|
4500*1680*2000 |
|
Cargo Size(mm)
|
3420×1550×1510 |
|
Van cargo volume (m³)
|
8 |
|
Wheel Base(mm)
|
3050 |
|
Front Tread(mm)
|
1435 |
|
Rear Tread(mm)
|
1435 |
|
Min.Ground Clearance(mm)
|
188(no-load) |
|
Curb Weight(kg)
|
1575 |
|
payload(kg)
|
560 |
|
Rear door opening mode
|
●Side sliding door |
|
Max Speed (km/h)
|
100 |
|
Electric drive and rear axle
|
|
| Motor model | Motor(FOUNDER):TZ205XSFDM Permanent Magnet Synchronous Motor,Controller(INVT):KTZ34X29S520 |
|
Rated power (kW)/rated speed (rpm)
|
30/3600 |
|
Peak power (kW)/peak speed (rpm)
|
60/9000 |
| Rated torque (N.m)/Max. torque (N.m) | 80/200 |
|
Speed ratio
|
10.5 |
| Power battery | Lithium iron phosphate battery |
|
Battery pack heating
|
● |
|
Power battery capacity (kWh)
|
38.6 |
|
Range(km)
|
≥252 |
| Charging time(h) | Fast charging SOC(20%-80% )1.3h,(0-100%)2.5h,slow charging 7-8h |
|
System structure
|
|
| Body type | Unitary construction body:double sliding doors |
|
Drive mode
|
Rear egine, rear drive |
| Front suspension | MacPherson Independent Suspension |
| Rear suspension | Non-independent 5-leaf spring suspension |
| Brake | Front disc and rear drum, mechanical brake |
|
Steering type
|
EPS |
|
External Configuration
|
|
|
Tire
|
185R14LT 8PR |
|
Wheel rim
|
Steel wheel |
|
Wheel cover
|
● |
|
Front/rear mudguard
|
● |
| Electrically adjustable front combination headlight | ● |
|
Front fog light
|
● |
|
Indicator
|
● |
|
Front wiper with bone
|
● |
| Exterior rear-view mirror with electric adjustment | ● |
|
Electric lift for front window
|
● |
| Sliding door rail trim (double sliding doors) | ● |
| Rear combination lights (double reversing lights) | ● |
|
Rear double fog lights
|
● |
|
Retro reflector
|
● |
|
High-mount brake light
|
● |
|
Body exterior trim
|
● |
|
Rear license plate light cover
|
● |
| Charging interface | Standard: National standard AC charging 32A (6.6kW), DC charging MAX80A Optional: European standard AC charging 32A (6.6kW), DC charging MAX80A |
|
Opening of charging port cover
|
Key (fast charging interface) |
|
Protection plate for battery pack
|
● |
|
Internal configuration
|
|
|
Nissan black interior style
|
● |
|
Sun visor
|
●(without make-up mirrior and light) |
|
Inside rear-view mirror
|
● |
|
Dashboard
|
Nissan black |
|
4 speakers
|
● |
|
Warm air manipulation mechanism
|
● |
|
Ash box
|
● |
|
Cigarette lighter
|
● |
|
General steering wheel
|
● |
| The upper and lower covers of the combination switch | ● |
|
Gear-shift
|
Knob shift |
| Control box + rear cover + cup holder | Nissan black control box; with cup holder, |
|
Interior lights (front/middle/rear)
|
● |
|
Front door light switch
|
● |
|
Rear door light switch
|
● |
|
Horn
|
High pitch, spiral shape |
|
A/C with double steam
|
● |
|
A pillar trim
|
● |
|
Top roof
|
● |
|
Safety handle
|
5 |
| Seats | Split seat for 7 people : 2+2+3; fabric: M080+M081; Nissan black seat trim |
| Front-row seats | C37 seat, 4-way adjustment for the driver seat and front passenger seat + Nissan black decorative plate, seat belt lock is fixed on the floor |
| Second-row seats | Split seat for 7 people: with sliding rail, adjustable backrest, Nissan black decorative plate, seat belt lock is fixed on the floor |
| Third-row seats | Split seat for 7 people: middle seat with seat belt |
| Safety belt | Nissan black webbing and cover (three-point type), ordinary seat belt (with emergency locking retractor) second row:split seat for 7 people:3+3；8 seats:2+2+3 third row:split seat for 7 people:3+3+3；8 seats:3+2+3 |
| Floor mat | Front floor carpet: M023 grey lychee pattern 1.6mm foam + noise insulation cotton, split type. Insulation carpet of engine compartment : M023 grey lychee pattern 1.6mm foam+EVA. Rear floor carpet: M023 grey lychee pattern 1.6mm foam + noise insulation cotton |
|
Front panel insulation pad
|
● |
|
Floor mat
|
Nissan black |
|
Flooring strips/steps
|
Nissan black |
|
Security , intelligence
|
|
|
Child lock
|
● |
|
ISOFIX
|
Basic: IA Optional: NA (8 seats) |
|
ABS/EBD
|
● |
|
Reversing radar
|
● |
|
Central lock
|
● |
|
Remote control Key
|
● |
|
Slow charging
|
● |
|
Fast charging
|
● |
|
Low-speed pedestrian warning
|
● |
|
Others
|
|
|
Mechanical jack
|
● |
“●”——Indicates that this configuration is available, “○”——Indicates that this configuration is optional,
“-”——Indicates that this configuration is not available
Ruichi ES50 Feature
Ruichi ES50 Pure electric mini truck
Large space, commercial or passenger
