Product Details:
|
|
| Place of Origin: | Chongqing, China |
|---|---|
| Brand Name: | RUICHI |
| Model Number: | EC35II |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 unit |
| Price: | Negotiable |
| Packaging Details: | By Container |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 70000 units per year |
|
Detail Information |
|||
| Product Name: | EC35II | Fuel: | New Energy |
|---|---|---|---|
| Passenger: | 2/5 | Cargo Volume Of Van (m³): | 5.3/3.1 |
| Exterior Dimension: | 4500*1680*2000 Mm | Cargo Size: | 2530/1630*1440*1270 Mm |
| Power Battery Capacity (kWh): | 38.64/38.4 | Cruising Range Under Load (CLTC): | 274/282 Km |
| Power: | 60 KW | Max Speed (km/h): | 80 |
| Highlight: | RUICHI Electric Vans and Trucks,EC35II Cargo Electric Vans and Trucks,ev electric mini van |
||
Product Description
Ruichi EC35II Specification
|
Items |
EC35II |
EC35II |
|
|
Champion Edition-Pioneer I | Champion Edition-Pioneer II |
|
Basic Parameter |
||
|
Size (mm) |
4500*1680*2000 | |
|
Cargo Size (mm) |
2530/1630*1440*1270 | |
|
Curb weight (kg) |
1460/1495, 1435/1465 | 1445/1475 |
|
Rated load capacity(kg) |
1010/780, 1035/810 | 1025/800 |
|
Wheelbase (mm) |
3050 | |
|
Front wheel track (mm) |
1435 | |
|
Rear track (mm) |
1435 | |
|
Number of doors |
5 | |
|
Cargo volume of van (m³) |
5.3/3.1 | |
|
Max speed (km/h) |
80 | |
|
Seater |
2/5 | |
|
Rear door opening mode |
●Sliding door | |
|
Sliding door type |
Manual | |
|
Electric Drive and Rear Axle |
||
|
Max speed (km/h) |
80 | |
|
Total motor power (kw) |
60 | |
|
Battery Type |
Lithium Iron Phosphate | |
|
Rated Torque (N.m) |
220 | |
|
Number of drive motors |
1 | |
|
Motor layout |
Sideways | |
|
Power battery capacity (kWh) |
38.64/38.4 | 38.64 |
|
Cruising range under load (CLTC) |
274/282 | 282 |
|
Chassis steering |
||
|
Drive mode |
Rear-mounted rear-wheel drive | |
|
Front suspension type |
McPherson independent suspension | |
|
Rear suspension type |
Longitudinal leaf spring non-independent suspension | |
|
Power type |
Electronic power steering (EPS) | |
|
Front brake type |
Disc brake | |
|
Rear brake type |
Drum brake | |
|
Parking brake type |
Mechanical | |
|
Front/rear tire specifications |
185R14LT 8PR | |
|
Active/passive safety equipment |
||
|
Passive pedestrian protection device |
Seat belt | |
|
Seat belt unfastened reminder |
● | |
|
ABS anti-lock braking system |
● | |
|
Brake force distribution (EBD/CBC, etc.) |
● | |
|
Reversing radar |
● | |
|
External/anti-theft configuration |
||
|
Central locking system inside the car |
● | |
|
Front/rear electric windows |
Front | |
|
Remote control key |
● | |
|
Multimedia configuration |
||
|
Radio (with MP3) |
● | |
|
Number of speakers |
2 | |
|
Lighting configuration |
||
|
Headlights |
Halogen | |
|
Height-adjustable headlights |
● | |
|
Seat configuration |
||
|
Seat material |
Fabric | |
|
Driver seat adjustment mode |
Front and rear adjustment + backrest adjustment | |
|
Passenger seat adjustment mode |
Front and rear adjustment + backrest adjustment | |
|
Air conditioning |
●Manual | |
"●" - indicates that this configuration is available, "○" - indicates that this configuration is optional,
and "-" - indicates that there is no such configuration;
DFSK Ruichi EC35II Advantages Introduction
![]()
About RuiChi EC35II:
As an electric microvan that has been ranked first in sales in the same class, the Ruichi New Energy EC35 has a 2-seat and
5-seat layout design, which is convenient for carrying people and cargo. The overall design is square and simple, highlighting
its unique new energy identity.
1. External dimensions: length, width and height are 4500x1680x2000mm respectively, wheelbase is 3050mm, cargo compartment
size: length, height and width of 2-seat and 5-seat are 2530/1630X1440x1270mm respectively.
2. Interior decoration: The center console uses the classic T-shaped layout, providing a large-size center control screen with a multimedia system,
front/rear parking radar and front fog lights
3. Battery power: It adopts a pure electric drive mode, with a maximum output power of 60kW (82PS) and a peak torque of 191N·m.
Different configurations can be selected with a maximum cruising range of 282KM to 274KM!
![]()
![]()
![]()
![]()
![]()
![]()
