Product Details:
|
|
| Place of Origin: | Chongqing, China |
|---|---|
| Brand Name: | DFSK |
| Model Number: | EC31 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 unit |
| Price: | Negotiable |
| Packaging Details: | By Container |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 90000 units per year |
|
Detail Information |
|||
| Product Name: | DFSK EC31 Small Refrigerated Box Truck | Type: | Electric Refrigerated Truck |
|---|---|---|---|
| Fuel: | New Energy | Temperature Range: | -20C To +12C |
| Exterior Dimension (mm): | 4735×1635×2440 Mm | Cargo Size: | 2660×1450×1430 Mm |
| Battery Capacity: | 38.64 KWh | Max. Mileage: | 275 Km |
| Power: | 60 KW | Fast Charing: | 0.6 H |
| Drive Type: | Left/Right | ||
| Highlight: | DFSK Electric Freezer Cargo Truck,Electric Freezer Cargo Truck Food Delivery,EC31 Small Refrigerated Box Truck |
||
Product Description
EC31 Small Refrigerated Box Truck Specification
|
Ruichi EC31 Electric Freezer Cargo Truck
|
|
|
Basic
|
|
|
Size (mm)
|
4735×1635×2440 |
|
Body Type
|
load-bearing body |
|
Body
|
|
|
Length (mm)
|
4735 |
|
Width (mm)
|
1635 |
|
High (mm)
|
2440 |
|
Wheel tread (mm)
|
3050 |
|
Front Wheelbase (mm)
|
1410 |
|
Rear Wheelbase (mm)
|
1410 |
|
Curb weight (kg)
|
1570 |
|
Door
|
2 |
|
Seat
|
2 |
|
Cargo Size (mm)
|
2660×1450×1430 |
|
Van cargo volume (m³)
|
5.5 |
|
Rated load mass (kg)
|
900 |
|
Max Speed (km/h)
|
80 |
|
Approach angle (°)
|
30 |
|
Departure angle (°)
|
35 |
|
Power
|
|
|
Motor type
|
Permanent magnet synchronous motor |
|
Battery type
|
Lithium Iron Phosphate |
|
Total motor power (kw)
|
60 |
|
Total motor torque
|
220 |
|
Number of drive motors
|
1 |
|
Motor layout
|
Horizontal |
|
Operating mileage (CLTC)
|
275 |
|
Operating mileage (NEDC)
|
/ |
|
Battery capacity
|
38.64 |
|
Electricity consumption per 100 kilometers (calculated value)
|
|
|
Battery pack warranty
|
8 years or 400,000 kilometers |
|
Battery heating function
|
● |
|
Chassis steering
|
|
|
Drive mode
|
RWD |
|
Front suspension type
|
MacPherson independent suspension |
|
Rear suspension type
|
Longitudinal leaf spring non-independent suspension |
|
Assist type
|
Electronic Assistance (EPS) |
|
Body structure
|
load-bearing body |
|
Wheel brake
|
|
|
Front brake type
|
Disc brakes |
|
Rear brake type
|
Drum brake |
|
Parking brake type
|
Mechanical |
|
Front Rear tire specifications
|
185R14LT 8PR |
|
Active/passive safety equipment
|
|
|
Passive pedestrian protection device
|
Seat belt |
|
Seat belt not fastened reminder
|
● |
|
ABS anti-lock
|
● |
|
Braking force distribution (EBD/CBC, etc.)
|
● |
|
External/anti-theft configuration
|
|
|
Central locking in car
|
● |
|
Front/rear electric windows
|
Front |
|
Remote key
|
● |
|
Multimedia configuration
|
|
|
Number of speakers
|
2 |
|
Lighting configuration
|
|
|
Headlight
|
Halogen |
|
Headlight height adjustable
|
● |
|
Seat configuration
|
|
|
Driver/Passenger seat adjustment form
|
Backrest adjustment |
|
Air
|
|
|
Air conditioning temperature control method
|
●Manual |
"●" - indicates that this configuration is available, "○" - indicates that this configuration is optional,
and "-" - indicates that there is no such configuration;
EC31 Small Refrigerated Box Truck Description
EC31 as an electric refrigerated van truck
EC31 is 100% fully electric freezer van truck,it is also an excellent electric refrigerated truck when with refrigerated cargo box and chiller.
DFSK EC31 Small Electric Trucks 275km Mile Range Per Charging.
At same time, the EC31 as an electric refrigerated box truck, the the temperature control range is -20 degree C to +12 degree C,which is very good for food delivery.
DFSK EC31 Small Electric Trucks Fast Charging, Approved for Fast Charging,90 mins
EC31 have the EU EEC/COC Certification, and our facotry can provide LHD and RHD small truck of EC31,
have air conditioner in driving room.
