Product Details:
|
|
| Place of Origin: | Chongqing, China |
|---|---|
| Brand Name: | Ruichi |
| Model Number: | EK01S |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 unit |
| Price: | Negotiable |
| Packaging Details: | By Container |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 80000 units per year |
|
Detail Information |
|||
| Product Name: | Ruichi | Size: | 4435*1560*1820 Mm |
|---|---|---|---|
| Type: | MINI TRUCK | CLTC（km）: | 221 |
| Number Of Seat: | 2 | Wheelbase: | 2760 Mm |
| Max Speed: | 80 Km/hour | Battery Capacity: | 31.25 Kwh |
| Max Power (kW): | 45 | Total Torque (N·m): | 150 |
| Highlight: | Ruichi EK01S Electric Cargo Truck Pickup Van,New Energy Electric Cargo Truck,4 Wheel Electric Cargo Truck |
||
Product Description
Electric Truck Ruichi Ek01s Van Pickup Cargo Electric 4 Wheel Electric Car Pickup EV Car New Energy Vehicle Truck Electric Car
Specifiction
|
Ruichi EK01S Mini Truck
|
||
| Item | EK01S cargo | EK01S cargo box |
|
Basic
|
||
| Size (mm) | 4435×1560×1820 | 4465×1560×2410 |
| Body Type | load-bearing body | |
|
Body
|
||
| Length (mm) | 4435 | 4435 |
| Width (mm) | 1560 | 1560 |
| High (mm) | 1820 | 1820 |
| Wheel tread (mm) | 2765 | |
| Front Wheelbase (mm) | 1290 | |
| Rear Wheelbase (mm) | 1290 | |
| Curb weight (kg) | 1070 | 1200 |
| Door | 2 | |
| Seat | 2 | |
| Cargo Size (mm) | 2770×1440×370 | 2620×1450×1610 |
|
Van cargo volume (m³) |
6.1 | |
| Rated load mass (kg) | 850 | 720 |
| Max Speed (km/h) | 80 | |
| Approach angle (°) | 32 | |
| Departure angle (°) | 29 | |
|
Power
|
||
| Motor type | Permanent magnet synchronous motor | |
| Battery type | Lithium Iron Phosphate | |
| Total motor power (kw) | 45 | |
| Total motor torque | 150 | |
| Number of drive motors | 1 | |
| Motor layout | Horizontal | |
| Operating mileage (CLTC) | 221 | |
| Operating mileage (NEDC) | / | |
| Battery capacity | 31.25 | |
| Battery heating function | ● | |
|
Chassis steering
|
||
| Drive mode | RWD | |
| Front suspension type | MacPherson independent suspension | |
| Rear suspension type | Longitudinal leaf spring non-independent suspension | |
| Assist type | Electronic Assistance (EPS) | |
| Body structure | load-bearing body | |
|
Wheel brake
|
||
| Front brake type | Disc brakes | |
| Rear brake type | Drum brake | |
| Parking brake type | Mechanical | |
| Front Rear tire specifications | 185R14LT 8PR | |
|
Active/passive safety equipment
|
||
| Passive pedestrian protection device | Seat belt | |
| Seat belt not fastened reminder | ● | |
| ABS anti-lock | ● | |
| Braking force distribution (EBD/CBC, etc.) | ● | |
|
External/anti-theft configuration
|
||
|
Central locking in car |
● | |
| Front/rear electric windows | Front | |
| Remote key | ● | |
|
Multimedia configuration
|
||
| Radio (with MP3) | ● | |
| Number of speakers | 2 | |
|
Lighting configuration
|
||
| Headlight | Halogen | |
| Headlight height adjustable | ● | |
|
Seat configuration
|
||
| Driver/Passenger seat adjustment form | Backrest adjustment | |
|
Air
|
||
| Air conditioning temperature control method | ●Manual | |
Features
The Ruichi EK01S is a versatile electric mini truck, designed for urban logistics and short-distance transport. With a loading capacity of 720 kg and a spacious 6 cubic meter container, this electric truck offers an eco-friendly solution for businesses. Manufactured in China and compliant with CCC certification, the Ruichi EK01S meets the growing demand for electric vehicles in the commercial sector.
Key Features and Specifications of Ruichi EK01S
Power Output: The truck is powered by a 45 kW Permanent Magnet Synchronous Motor (PMSM), offering solid performance for urban and short-distance driving.
Battery Type: Equipped with a reliable ternary lithium battery, the Ruichi EK01S ensures long-lasting efficiency.
Transmission: A single-speed transmission simplifies operation, making it easy to drive in city environments.
NEDC Range: With a driving range of 221 km on a single charge, this electric truck is suitable for a full day of work without needing frequent recharges.
Max Power: The motor delivers a peak power of 45 kW, allowing it to handle both light and medium cargo loads with ease.
Dimensions and Build
The Ruichi EK01S is compact yet spacious, with body dimensions of 4435 mm (length), 1560 mm (width), and 2410 mm (height). This closed-body design makes it suitable for transporting goods securely while navigating narrow city streets.
Seating Capacity: The truck has space for 2 passengers, making it a practical option for deliveries or urban transport services.
Body Type: Closed, providing extra protection for the cargo and ensuring it stays secure during transportation.
Performance and Utility
Loading Capacity: The Ruichi EK01S boasts a 720 kg payload capacity, which is ideal for transporting small to medium loads efficiently.
Cargo Space: The truck is equipped with a 6 cubic meter container, offering ample room for goods, making it a strong competitor in the mini electric truck category.
Compared to other electric mini trucks, the Ruichi EK01S offers a better balance of range, power, and capacity, making it ideal for businesses looking for cost-effective, environmentally friendly solutions. With a range of 280 km, it outperforms many competitors in the same category.
Conclusion
The Ruichi EK01S Electric Mini Truck is a well-rounded, eco-friendly vehicle designed for urban logistics and commercial use. Its high payload capacity, spacious cargo area, and long driving range make it a top choice for businesses looking to switch to electric vehicles.
