Product Details:
|
|
| Place of Origin: | Chongqing, China |
|---|---|
| Brand Name: | DFSK |
| Model Number: | K01S |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 unit |
| Price: | Negotiable |
| Packaging Details: | By Container |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 80000 units per year |
|
Detail Information |
|||
| Product Name: | DFSK K01S K01S | Seats: | 2 |
|---|---|---|---|
| Displacement（L）: | 1.05/1.24 | Steering: | RHD |
| Max Spped (km/h): | 110/120 | Displacement (cc): | 1050/1240 |
| Transmission Type: | 5MT | Fuel Tank: | 40L |
| Body Type: | Semi-loaded Body (power Upgrade) | Interior Trim Style: | Black |
| Highlight: | 110km/h RHD Vehicles,120km/h RHD Vehicles,DFSK K01S mini mini work trucks |
||
Product Description
RHD Mini Truck Update DFSK K01S Work Trucks For Sale
Specification
|
Item
|
Dongfeng export right-hand drive-non-European standard-standard type II (R3)
|
|
|
Engine and rear axle
|
||
|
Engine
|
AF10-13 | DK12-05 |
|
Speed Ratio
|
Normal rear axle(41:8) | Normal rear axle(41:8) |
|
Emission Standard
|
China V | China III without OBD/China Ⅳ |
|
Displacement(L)
|
1.05 | 1.24 |
|
EFI
|
Delphi MT22.1/LINGDIAN LEC4AF | UMC M7.8.1 |
|
Transmission Type
|
5MT | |
|
System structure
|
||
|
Body type
|
Semi-loaded body (power upgrade) | |
|
Drive Mode
|
Mid-engine, rear-drive | |
|
Front Suspension
|
MacPherson Independent Suspension | |
| Rear Suspension | basic:Non-independent 5-leaf spring suspension optional:Non-independent 6-leaf spring suspension |
|
|
Brake
|
Front-disc rear drum, dual circuit hydraulic brake | |
| Steering Type | basic:Mechanic optional:EPS |
|
|
Clutch type
|
Mechanic | |
|
External configuration
|
||
| Tire | basic:165/70R14 optional:165R13LT |
|
| Wheel Rim |
basic:silver steel wheel,silver steel spare tire (Optional aluminum wheels only for 165/70R14) |
|
| Wheel Rim Cover | basic:decorative cover of steel wheel (DONGFENG logo, optional SOKON logo) optional:decorative cover of aluminum wheel |
|
| Wheel nut | basic:galvanized nut optional:chrome plated nut |
|
|
Front/rear bumper
|
Front bumper:body color(K07S) | |
| Grille | Integrated with front bumper, body color(K07S) optional: black leather for upper grille + chrome decorative strip |
|
|
Front/Rear Mudguard
|
IA | |
|
Front Headlamp
|
Single headlamp with electric height adjustment (new shape) | |
|
Front Fog Light
|
IA | |
| Daytime running light | basic:NA optional:IA |
|
|
Indicator
|
Yellow light bulb with white shade(from C37) | |
|
Wiper
|
Front wiper with bone, without rear wiper | |
|
Exterior Rear-View Mirror
|
Enlarged exterior rear-view mirror, same color of mirror shell , mirror base in black | |
| Outside Handle | Basic: Black (from K07) Optional: chrome (from K07) |
|
|
Glass
|
Lift glass for front door | |
| Window Glass Lifter | basic:manual front door optional:electric front door |
|
|
Outer cut water glue strip
|
Black | |
|
Rear Headlamp
|
Double reversing lights, rear combination light strip (K01) | |
|
Rear fog light
|
Double rear fog lights, rear combination light strip(K01) | |
|
Retro Reflector
|
Non-Independent, rear combination light strip | |
| High-Mount Brake Light | basic:NA optional:IA |
|
| Car Identification | Front logo:DONGFENG LOGO nameplate:hard rear sign:K01S |
|
|
Decal
|
Decal for back: Logo + DFSK | |
|
Muffler Heat Sheild
|
NA | |
|
Muffler Cover
|
NA | |
| Engine Cover | basic:NA optional:IA |
|
|
Engine Decoration
|
NA | |
|
Fuel Tank
|
40L,galvanized metal fuel tank | |
|
Fuel Tank Opening Mode
|
Key | |
|
Internal Configuration
|
||
|
Interior Trim Style
|
Black | |
|
Sun Visor
|
Gray, double-visor (standard type), driver seat with ticket belt, front passenger seat with make-up mirror | |
| Inside Rear-View Mirror | basic:basic type, gray, front reading light optional:basic type, gray,manual anti-glare, front reading light |
|
| Dashboard | Nissan black body: titanium silver side air vents, center control panel and dashboard cover Nissan black toolbox lock handle and hood release handle |
|
|
Combination instrument
|
basic: Digital(with tachometer) | |
| Multi-Media System | basic:Electric tuning radio optinal:MP3 |
|
|
Speaker
|
2 | |
| Warm air manipulation mechanism | Manual type | |
|
Cigarette Lighter
|
IA | |
|
Ash box
|
IA | |
| Steering Wheel | basic:three-spoke steering wheel (DONGFENG logo, optional SOKON logo) optional:four-spoke steering wheel |
|
|
Adjustable steering wheel
|
NA | |
| Upper & Down Cover of Combination Switch | basic: New shape of upper & down cover (same as C07),Nissan black optional:K-Series,Nissan black |
|
|
Gear-Shift
|
from V07S,Nissan black | Chrome-plated trim for gear(from new K07) |
|
Hand Brake
|
from V07S,Nissan black | |
| Control box + rear cover + cup holder | Nissan black | |
| Interior lights (front/middle/rear) | Integrated with front reading light and interior mirror , without any logo | |
|
Front door light switch
|
basic:NA optional:IA |
|
|
Rear door light switch
|
NA | |
|
Horn
|
Basin type | |
| A/C | basic:NA optional:A/C with single steam |
|
| Interior trim panels (door/side) | basic: standard heat-sealing lines, Nissan black artificial leather optional:K01H shaped injection-molded interior panel, without triangular trim pieces, Nissan black body, silver trim pieces and cover ; Nissan black armrest cover (when electric windows and doors are available) |
|
|
Pillar trim
|
NA | |
|
Top roof
|
Hardtop, non-woven, gray | |
|
Safety Handle
|
1,gray | |
| Handle (mounted on the pillar) | NA | |
| Handrail + crank handle | basic:front door, Nissan black,common type of K series optional:front door,Nissan black, interior panel with handle |
|
| Interior Handle | basic:front door, Nissan black,common type of K series optional:front door,Nissan black (KP01 interior handle), injection molded interior panel |
|
|
Locking button + bushing
|
Nissan black | |
|
Seats
|
K01 seat,fabric:M001+M016 | |
|
Front-Row seats
|
Driver seat and front passenger seat with sliding rail, headrest is fixed to the rear panel,seat belt lock on the floor | |
|
Second-Row Seats
|
NA | |
|
Seat Hinged Cover
|
NA | |
| Safety belt | Nissan black front row: 3+3, common type |
|
|
Floor Mat
|
Front:M015,2.0mm foam | |
|
Carpet noise insulation cotton
|
NA | |
|
Front floor insulation pad
|
IA | |
|
Floor Mat
|
Nissan black | |
|
Flooring strips/steps
|
NA | |
|
Security and intelligence
|
||
|
Airbag
|
NA | |
|
Child lock
|
NA | |
| ABS/EBD | basic:NA optional:IA |
|
| Central Lock | basic:NA optional:remote central control for front door |
|
|
Key
|
Integrated key(DONGFENG logo, optional SOKON logo) | |
| ESP/ESC | NA | |
| Immobilizer | NA | |
| Body Anti-Theft | NA | |
| TPMS | NA | |
| EBA/BAS/BA/EVA | NA | |
|
Body description
|
||
| Cargo Compartment | Basic: 2.3m cargo box, without rear fence and lift rail optional:2.5m cargo box, without rear fence and lift rail 2.7m cargo box, without rear fence and lift rail |
|
| Guard bar for rear side window glass | IA | |
| rear metal bumper | basic:NA optional:IA |
|
| Tool Box | basic:NA optional:IA |
|
|
Others
|
||
|
Battery Tray
|
NA | |
|
Visible standard parts
|
Army green | |
“●”——Indicates that this configuration is available, “○”——Indicates that this configuration is optional,
“-”——Indicates that this configuration is not available
