Product Details:
|
|
| Place of Origin: | Chongqing,China |
|---|---|
| Brand Name: | DFSK |
| Model Number: | EC35 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 |
| Delivery Time: | 10-15 working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 80000 units per year |
|
Detail Information |
|||
| Name: | DFSK EC35 | Steering: | Right Hand Drive |
|---|---|---|---|
| Van Size: | 4500*1680*1985 Mm | Wheelbase: | 3050 Mm |
| Max Speed: | 80-100 Km/hour | Battery: | Lithium Iron Phosphate |
| Battery Capacity: | 38.7 Kwh | Cargo Box Size: | 2570*1440*1270 Mm |
| WLTP Range: | 268 Km | Charging Type: | AC & DC |
| Highlight: | DFSK EC35 RHD Vehicles,RHD Vehicles 80km/hour,100km/hour Electric Cargo Van |
||
Product Description
DFSK EC35 RHD EV Right Hand Drive Electric Cargo Van
DFSK EC35 Right Hand Drive Electric Cargo Van Specification:
| Item |
R1
|
|
|
Basic
|
Optional
|
|
|
Gotion (Lithium Iron Phosphate)
|
||
|
Basic Parameter
|
||
|
Length × Width × Height (mm)
|
Box van:4500*1680*1985 | |
|
Wheelbase (mm)
|
3050 | |
|
Wheel tread (mm)
|
1435/1435 | |
|
Curb weight (kg)
|
1510 | |
|
Gross weight kg
|
2600 | |
|
Acceleration time of 0-50km/h
|
＜10S | |
|
Acceleration time of 50-80kW/h
|
＜15S | |
|
Max Speed (km/h)
|
80 | 100 |
|
Seating capacity
|
2 | 2+2 |
|
Electric drive and rear axle
|
||
| Motor Type | Greatland: TZ210XSR41Permanent Magnet Synchronous Motor |
|
|
Motor Cooling Method
|
Water cooling | |
|
Rated Power/Peak Power (KW/rpm)
|
30/3600—60/9000 | |
|
Rated torque / Peak torque(N.m)
|
80/200 | |
|
Drive axle speed ratio
|
10.5 | |
|
Estimated Range [WLTP]
|
Max. speed 80:268km | Max. speed 100:163km |
|
Voltage
|
307.2 | |
|
Battery capacity kWh
|
38.7 standard:With heating and maintenance switch | |
|
OBC power
|
6.6KW | |
|
Transmission/Reducer
|
NA | |
|
System structure
|
||
|
Body Type
|
Integral body | |
|
Drive Mode
|
Rear egine, rear drive | |
|
Front Suspension
|
MacPherson Independent Suspension | |
|
Rear Suspension
|
Non-independent 5-leaf-spring suspension | |
|
Brake
|
Front disc and rear drum, Mechanical Parking Brake | |
|
Steering Type
|
EPS | |
|
External Configuration
|
||
|
Tire
|
185R14LT 8PR | |
|
Tire Rim
|
Silver steel wheel( optional black steel spare tire ) | |
|
Wheel Cover
|
Steel wheel decoration cover (DFSK logo) | Steel wheel decoration cover (SOKON logo) |
|
Wheel Nut
|
Galvanized nuts | |
|
Front/Rear Bumper
|
the same color | |
|
Grille
|
same color | |
|
Front/rear mudguard
|
IA,without logo | |
|
Front combination headlight
|
European standard regulation requirements: automatic headlight lighting function | |
|
Front fog light
|
IA | |
|
Daytime running light
|
European standard regulation requirements:IA | |
|
Side turn signal
|
White lamp shade and yellow light bulb | |
|
Wiper
|
Front wiper( with bone ) | |
| Exterior Rear view Mirror | Standard type, matt black, external manual adjustment | Electric Exterior Rearview Mirror |
|
Sunroof
|
NA | |
|
Outer handle
|
Matt black | |
| Glass | 2 seats:lift glass for front door,panel for middle sliding door/rear side ；glass for back door | |
| 4 seats:lift glass for front door,glass for middle door;glass for back door,panel for rear side | ||
|
Glass lifter
|
electric front door | |
|
Pillar black film
|
NA | |
|
External cut glue strip
|
IA | |
|
Sliding door/rail decoration
|
Double sliding doors: matt black trim | |
|
Rear combination light
|
Double Reverse Lights | |
|
Rear fog light
|
Double Fog Lights | |
|
Retro reflector
|
Independent retro reflector | |
|
High Mounted Stop Lamp
|
IA | |
|
Reflective Logo
|
NA | |
|
Car Spoiler
|
NA | |
| Exterior decoration | Front door trim: matt black; exterior trim of fender: matt black; D-pillar trim: body color; rear headlight trim: black leather pattern |
|
|
Rear license plate lamp cover
|
body color | |
| Full Vehicle Logo | Model number:DFSK EC35 rear sign:NA Logo:DFSK Nameplate:soft(English for European standard ) |
Model number:NA rear sign:NA Logo:SOKON Nameplate:soft(English for European standard ) |
| Luggage rack | NA | |
|
External spray pattern decoration
|
Customizable | |
| Side protection plate for battery pack | NA | |
| Motor protective cover | NA | |
| Big surrounded | NA | |
|
Internal configuration
|
||
|
Interior style
|
Black interior | |
|
Sun visor
|
Yellow,double visors without make-up mirrior | |
|
Inside rear view mirror
|
Nissan black, adhesive, with anti-glare | |
| Dashboard | Combination instrument requirements: White background light + charge display +unfastened reminder of seat belt + unclosed reminder of door+ range display (English display, metricinstrument) |
Combination instrument requirements: White background light + charge display +unfastened reminder of seat belt + unclosed reminder of door+ range display ( Display in English, imperial gauge dial shows MPH + km/h, LCD shows MPH)To be certified |
|
Audio-visual system
|
MP5 ,DAB radio,multiple language options | |
|
Speaker
|
2 | |
|
Warm air operation mechanism
|
Titanium silver three-knob decorative ring , Nissan black body | |
| Cigarette lighter | IA | |
| Ashtray | IA | |
|
Steering wheel
|
Multifunction steering wheel+DFSK Logo+Airbag | SOKON status without airbag |
| Adjustable steering wheel | NA | |
| Combination switch upper and lower cover | Nissan Black | |
|
Shift control mechanism
|
Knob type | |
|
Handbrake
|
Mechanical handbrake | |
|
Control box + cup holder
|
Nissan black control box; without rear cover,with cup holder | |
|
Indoor lights (front/middle/rear)
|
Front reading light: yellow, 1 bulb; Rear interior light: single switch | |
| Front door light switch | IA | |
| Rear door light switch | IA | |
| Welcome light | NA | |
|
Horn
|
high-pitched, spiral type | |
|
Air Conditioning
|
Single steam | |
| Interior panel (door/side) | Front door: Nissan black, injection molded interior panel, with front triangular trim, Nissan black; middle door/ rear side/back door: Nissan black artificial leather | |
|
Column decoration
|
A pillar:yellow(with handle) | |
|
Roof
|
Hard top, non-woven, yellow | |
|
Safety handle
|
V27 design, yellow, 2 seats( 1 );4 seats ( 3 ) | |
| Car handle (installed on the column) | A-pillar handle: 1 each on the left and right, B-pillar handle: yellow. (2 seats are unavailable) / (4 seats 1 each on the left and right) | |
|
Front door armrest + swing handle
|
front door is available,middle door is unavailable | |
| Inner open handle | Front door: handle in matt grey, base in Nissan black Middle door: handle and handle base in Nissan black |
|
| Lock button + bushing | Front door: matte gray+ red warning strip Middle door: Nissan black |
|
|
Description of seats
|
fabric: M080+M081；Nissan black seat trim | |
| Front seats | Adjustable headrest, with side trim cover,seat belt latch on the floor； 4-way adjustment for the driver seat is equiped with slide rails and SBR gravity sensing function,height is not adjustable； 4-way adjustment for the front passenger seat is equiped with slide rails and SBR gravity sensing function,height is not adjustable； |
|
| Second-row seats | NA | one-piece extended seat for 3 people, basic headrest, seat belt latch on the floor；seat is equiped with SBR gravity sensing function |
| Third-row seats | NA | |
| Forth-row seats | NA | |
| Seat hinge cover | NA | |
|
Safety belt for front row
|
Nissan Black,3 - point | |
| Safety belt for second-row | NA | 3+3 |
| Safety belt for third-row | NA | |
| Safety belt for forth-row | NA | |
| Unbuckled reminder of seat belt | European standard regulation requirements: each seat needs to be equipped with unfastened reminder of seat belt (4 seats) | |
| Rear floor armor | PVC floor | Aluminum floor |
| Carpet noise insulation cotton | NA | |
| Front wall heat insulation pad | NA | |
|
Floor decoration
|
Nissan black footrest | |
|
Floor bead/step
|
Nissan black | |
| Storage box | NA | |
| Shelf | NA | |
|
Security , intelligence
|
||
|
Airbag
|
airbag for driver seat(DONGFENG Logo) | airbag for front passenger seat(to be developed) |
| Child lock | NA | |
| ISOFIX interface | NA | |
| ABS/EBD | IA | |
| Pedestrian alert system | IA | |
| Remote monitoring | NA | |
| Driving habit correction system | NA | |
| Reversing radar | IA | |
| Reversing video image | IA | |
|
Central control
|
Remote control | |
|
Key
|
Remote control + integrated style | |
| Rear defrost | IA | |
| Electric door | NA | |
| keyless entry & start system(PEPS) | NA | |
| BCM | NA | |
| Vehicle Controller (VCU) | IA | |
| Cruise control system | NA | |
| Panoramic parking system | NA | |
|
Navigation system (GPS)
|
Retention of GPS(No map navigation) | |
|
Electronic stability control(ESC)
|
IA(no certification) | |
| Electronic anti-theft system | NA | |
| Tire pressure monitoring system (TPM) | IA | |
| Traction Control System (ASR/TCS/TRC/ATC) | NA | |
| Emergency Brake Assist System (EBA/BAS/BA/EVA) | NA | |
| Electronic Parking Brake (EPB) | NA | |
| Slow charge | European standard integrated fast and slow charging | |
| Fast charge | ||
|
Body description
|
||
|
Grill/partition
|
Plastic partition | Aluminum partition |
|
Others
|
||
| Visual standard parts (including the visual range with five doors and one cover open) | Environmentally friendly standard parts | |
“●”——Indicates that this configuration is available, “○”——Indicates that this configuration is optional,
“-”——Indicates that this configuration is not available
